    LENOX MAX CT ™ CARBIDE BAND SAW BLADES

    Maximum Cutting Performance on Aerospace Alloys

    EXCEPTIONAL BLADE LIFE
    Multi-chip tooth pattern balances the chip load and reduces cutting forces
    Next generation welding technology prevents premature tooth loss

    FASTER, STRAIGHTER CUTS
    Aggressive rake angles aid in tooth penetration in difficult to cut metals
    Optimized gullet geometry increases beam strength for straighter cuts

    SUPERIOR PART FINISH
    Precision ground carbides create razor sharp teeth for a mirror-like finish on cut parts

    View the LENOX MAX CT Carbide Band Saw PDF

    Find Out More About WaveTech™

    Specifications

    WIDTH x THICKNESS TPI
    INCH MM 0.9/1.1 1.0/1.4 1.4/2.02/3
    1-1/4 x .042 34 x 1.07
    1-1/2 x .050 41 x 1.27
    2 x .050 54 x 1.27
    2 x .063 54 x 1.60 *
    2-5/8 x .063 67 x 1.60
    3 x .063 80 x 1.60
    *= Extra wide kerf
    • Nickel-Based Alloys (Inconel®)
    • Stainless Steels
    • Tool Steels
    • Titanium Alloys

    LENOX MAX CT LENOX CAST MASTER XL LENOX CAST MASTER XLE
    WIDTH OR DIAMETER OF CUT
    INCHES 1 2 3 4 5 6 7 8 10 11 14 16 18 20+
    MM 25 50 75 100 125 150 175 200 250 275 350 400 450 500+
       0.6/0.8
       0.9/1.1
       1.4/2.0
    2/3
